Air Dryer
| HEAT REGEN DRYER | . |
|---|---|
| Air Handling Capacity | 3000CFM/ 85Nm3/min (Continuous Flow) |
| Maximum Working Pressure | 30Bar / 3.0MPa |
| Maximum Dew Point Range | -70.C |
| Outlet Dewpoint Meter | Mitchell EA-TX-100 (Calibrated Range -70DP) |
| Inlet / Outlet Flange Size | 3″, 300#, RF Flange |
| Air Handling Hoses | 2″, 600psi, MNPT Threaded |
| Oil Mist Separator | 0.1 & 0.01 um Sieves |
| Skid Framing | 2510 x 2710 x 2896mm x 8MT2 |
| No of Units | 2 |
The primary function of the heat regen dryer is to take in cooled, high pressure air from market available high pressure compressors (rated working pressures of 25bar)
– Remove oil mist, via the oil mist separator
– Moisture from the air content via the desiccant tower
