DIESEL DRIVEN 3 STAGE CENTRIFUGAL FLOODING PUMP

DIESEL DRIVEN 3 STAGE CENTRIFUGAL FLOODING PUMP

OCS owned 3 staged pump (8V92 engine driven) units are skid mounted pumping unit that can be used for low pressure feed water or high pressure water. Main type of operations performed using these units are pipeline pre-commissioning, Pipeline post burial (Trenching) and Pile remedial operations using Jet/Airlift techniques. Three of the skids have been designed to accommodate 3 stage fluid ends (200SLD280-43X3) for pipeline flooding or pile jetting operations while the remaining two have been designed for low pressure/ high volume fluid ends (SLOW350-380B) to provide feed water to OCS high pressure / volume 4 stage pressure pumps. These are of course depends on the type of services required for.

The 3 stage pump is associated with the services as per below

  • PIPELINE SHORE APPROACHES
  • PIPELINE POST TRENCHING
  • PIPELINE PRE-COMMISSIONING
  • PILE REMEDIAL SERVICES
  • PRE TRENCHING SERVICES
  • WATER DISTRIBUTION SYSTEMS
3 stage pump specifications
Fluid End
200SLD280-43*3
Flow Rating
321 m3/hr
Suction Inlet
8” # 150
Discharge
8” # 150
Power Train
GM 8V-92TA 2 Stroke Diesel Engine
Power Output bhp (kW)
450 (336) @ 2100rpm
Peak Torque –lb ft (N.m)
1250 (1695) @1300rpm
Skid Framing
3800 x 1500 x 2420mm x 5MT
No Of Units
5

DIESEL DRIVEN 3 STAGE CENTRIFUGAL FLOODING PUMP Data Sheet Download
